碳化硅/氮化硅高温烧结炉

主要用于反应烧结碳化硅、氮化硅结合碳化硅的真空烧结行业。被广泛应用于军工、卫生及建筑陶瓷、航空航天、冶金、化工、机械、汽车等领域。

分享商品:

销售电话:15318905266

        碳化硅/氮化硅高温烧结炉

产品名称:碳化硅/氮化硅高温烧结炉

Name: Silicon carbide high temperature sintering furnace

主要用于反应烧结碳化硅、氮化硅结合碳化硅的真空烧结行业。被广泛应用于军工、卫生及建筑陶瓷、航空航天、冶金、化工、机械、汽车等领域。

碳化硅无压烧结炉适用于密封环、轴套轴管、喷嘴、叶轮、防弹产品等新兴陶瓷的碳化硅无压烧结工艺。

氮化硅陶瓷材料可用于高温工程的部件,冶金工业等方面的高级耐火材料,化工工业中抗腐蚀部件和密封部件,机械加工工业的刀具和刃具等

It is mainly used in vacuum sintering industry of reactive sintering silicon carbide and silicon nitride combined with silicon carbide. It is widely used in military industry, health and building ceramics, aerospace, metallurgy, chemical industry, machinery, automobile and other fields.

Silicon carbide pressure-free sintering furnace is suitable for silicon carbide pressure-free sintering process of sealing ring, shaft sleeve, nozzle, impeller, bulletproof products and so on.

Silicon nitride ceramic materials can be used in high temperature engineering components, advanced refractories in metallurgical industry, corrosion resistant and sealing parts in chemical industry, cutting tools and cutting tools in machining industry, etc.

特点 /characteristic

1. 高的温度均匀性和热效率

High temperature uniformity and thermal efficiency

2. 多区独立控温 、真空分压功能

Multi-zone independent temperature control, vacuum partial pressure function

3. 主体采用耐高温材质,满足细,中 粗颗粒料WC 粉和复合料碳化加热工艺

The main body adopts high temperature resistant material, which satisfies the carbonation heating process of fine and medium coarse granule WC powder and composite material.

4.采用温控组合方式

Adopt the combination mode of temperature control

5. 石墨隔热屏,石墨加热加热元件360度辐射加热

Graphite heat shield, graphite heating element,360-degree radiant heating

6.多种冷凝捕集方式减少机组污染

A variety of condensation trapping methods to reduce unit pollution

7.氮气吹扫系统绝缘更好,脱脂更彻底

Nitrogen purging system has better insulation and more thorough defatting.

8.专利绝缘方式,保证发热体长期使用

Patented insulation mode to ensure the long-term use of heating body

9.废气燃烧与过滤系统达到排放标准

Exhaust gas combustion and filtration system meets emission standard

配置选择/Configure select:

 炉型结构:

Furnace structure:

单室卧式 //Single, horizontal room

单室立式 /single,vertical chamber

可设计流水线组合,多台烧结炉共用一套真空系统,炉外运输系统

Can be designed assembly line combination, multiple sintering furnaces share a set of vacuum system, out-of-furnace transportation syst

 炉门开启方式: Furnace door opening mode

回转式

Rotary

平开式

Flat type



真空泵组和真空计;

Vacuum pump set and vacuum gauge



进口

Imported

高品质国产

High quality

Made in China



真空度:

Vacuum degree

中真空

Medium vacuum





 流量计

Flowmeter

 美国

America





PLC:



 西门子

Siemens

欧姆龙

OMRON

三菱

Mitsubishi

温控仪表

Thermostat meter

欧陆

EUROTHERM

导电

Electric conduction



热电偶 :

Thermocouple

 C分度号 (红外线测温)

C score number (infrared temperature measurement)

记录仪 :

Grapher :



 有纸记录仪

Paper recorder



无纸记录仪

Paperless recorder





 人机界面:

Human-computer interface

模拟屏

Analog screen



计算机触摸屏

Computer touch screen



电器元件

Electrical component

高品质国产

High quality

Made in China

施耐德

Schneider

西门子

Siemens



产品 规格/ Specifications

注:特殊规格要求可根据客户要求定制

Note: Special specification requirements can be customized according to customer requirements



以下参数可根据工艺要求调整,不作为验收依据,具体以技术方案和协议为准

The following parameters may be adjusted according to the process requirements and shall not be used as the basis for acceptance, depending on the technical scheme and agreement



 参数/型号

Parameter/ Model

PJ-SJ336

PJ-SJ447

PJ-SJ449

PJ-SJ4411

PJ-SJ5518

PJ-SJ7720

 有效热区W×H×L

Effective hot zone

300×300×600

400×400×700

400×400×900

400×400×1100

500×500×1800

700×700×3000

 装载重量 KG

Load weight

120

200

300

400

800

2000

 最高温度 (℃)

Max.temprature

2800

2800

2800

2800

2800

2800

 炉温均匀性 (℃)

Furnace temperature uniformity

±5-20

±5-20

±5-20

±5-20

±5-20

±5-20

 真空度 Pa

Vacuum degree

4.0 E -1/

6.7 E -3

4.0 E -1/

6.7 E -3

4.0 E -1/

6.7 E -3

4.0 E -1/

6.7 E -3

4.0 E -1/

6.7 E -3

4.0 E -1/

6.7 E -3

 压升率 Pa

Pressure rise rate

≤0.5

≤0.5

≤0.5

≤0.5

≤0.5

≤0.5

 冷却速度 min

Cooling velocity

可调

adjustable

可调

adjustable

可调

adjustable

可调

adjustable

可调

adjustable

可调

adjustable

 冷却介质

Cooling medium

 氩气/氮气

Argon / nitrogen

氩气/氮气

Argon / nitrogen

氩气/氮气

Argon / nitrogen

氩气/氮气

Argon / nitrogen

氩气/氮气

Argon / nitrogen

氩气/氮气

Argon / nitrogen

 脱脂工艺

Degreasing process

                  N2负压/H2大气压

N2 negative pressure / H2 atmospheric pressure

  烧结工艺

Sintering process

           真空/气压烧结(分压/微压/正压)

Vacuum / pressure sintering (partial pressure / micro pressure / positive pressure)

 冷却工艺

Cooling process

         真空/封闭(加压),强制(加压)

Vacuum/closed(pressurized), forced(pressurized).
