粉末金属注射成型真空烧结炉

用于粉末合金成型的脱气、脱脂、烧结一体化处理,适用于多品种,小批量注射成型产品,MIM专用设备。特点:1. 石墨隔热屏/金属屏可选,加热元件360度辐射加热,可靠的绝缘设计2. 高的温度均匀性和热效率

分享商品:

销售电话:15318905266

        粉末金属注射成型真空烧结炉

产品名称;粉末金属注射成型真空烧结炉

Name: Powder metal injection molding vacuum sintering furnace

用途:用于粉末合金成型的脱气、脱脂、烧结一体化处理,适用于多品种,小批量注射成型产品,MIM专用设备

Application: It is used for gas removal, defatting and sintering of powder alloy molding, suitable for multi-variety, small batch injection molding products, MIM special equipment

特点/Characteristics:

1. 石墨隔热屏/金属屏可选,加热元件360度辐射加热,可靠的绝缘设计

Graphite insulation screen / metal screen optional, heating element 360 degree radiation heating, reliable insulation design.

2.较高的温度均匀性和热效率

Higher temperature uniformity and thermal efficiency

3.真空分压/多区控温功能

Vacuum partial pressure / multi-area temperature control function.

4.设备完全自动化,完善的安全和异常报警系统

Fully automated equipment, perfect safety and abnormal alarm system.

5.精确的工艺控制以获得始终如一的零件质量,并防止零件和热区的污染

Accurate process control to achieve consistent part quality and prevent pollution of parts and hot areas

6. 密封脱脂箱与真空冷凝捕集器减少加热室与机组污染

Sealed defatting box and vacuum condenser to reduce pollution of heating chamber and unit.

配置选择/Configure select:



 炉型结构:

Furnace structure:

单室卧式 //Single, horizontal room

单室立式 /single, vertical chamber

可设计流水线组合,多台烧结炉共用一套真空系统,炉外运输系统

Can be designed assembly line combination, multiple sintering furnaces share a set of vacuum system, out-of-furnace transportation syst

 炉门开启方式: Furnace door opening mode

回转式

Rotary

平开式

Flat type



真空泵组和真空计;

Vacuum pump set and vacuum gauge



进口

Imported

高品质国产

High quality

Made in China



真空度:

Vacuum degree

高真空

High vacuum

中真空

Medium vacuum



PLC:



 西门子

Siemens

欧姆龙

OMRON

三菱

Mitsubishi

温控仪表

Thermostat meter

欧陆

EUROTHERM

导电

Electric conduction



热电偶 :

Thermocouple

C分度号(钨套管/钼套管)

C score number (tungsten casing / Mo casing)

记录仪 :

Grapher :



 有纸记录仪

Paper recorder



无纸记录仪

Paperless recorder





 人机界面:

Human-computer interface

模拟屏

Analog screen



计算机触摸屏

Computer touch screen



电器元件

Electrical component

高品质国产

High quality

Made in China

施耐德

Schneider

西门子

Siemens



产品 规格/ Specifications

注:特殊规格要求可根据客户要求定制

Note: Special specification requirements can be customized according to customer requirements



以下参数可根据工艺要求调整,不作为验收依据,具体以技术方案和协议为准

The following parameters may be adjusted according to the process requirements and shall not be used as the basis for acceptance, depending on the technical scheme and agreement.



技术参数

Technical parameter

PJSJ-gr-30-1600

PJSJ-gr-60-1600

PJSJ-gr-100-1600

PJSJ-gr-200-1600

PJSJ-gr-450-1600

有效空间 mm

Useful space

300×300×600

300×300×700

300×300×900

500×500×1200

700×700×2100

装炉重量 Kg

Charging weight

100KG

200KG

400KG

800KG

1200KG

抽气速率

Pumping rate

10min内到5Pa

10min内到5Pa

10min内到5Pa

10min内到5Pa

10min内到5Pa

冷却方式

Cooling-down method

惰性气体

Inert gases

惰性气体

Inert gases

惰性气体

Inert gases

惰性气体

Inert gases

惰性气体

Inert gases

最高温度

Max. temperature

1600

1600

1600

1600

16 00

温度均匀性

Temperature homogeneity

±3

±3

±3

±3

±3

加热功率

Heating power

65Kw

80 Kw

150 Kw

200 Kw

450 Kw

泄漏率pa/h

Leak(age) rate

0.5

极限真空度

Final vacuum

6.7*10-1Pa/ 6.7*10-3Pa

最高工作温度

Max. working temperature

 1600(或客制化)

1600 (or customized)

极限真空度

Final vacuum

 4.0*10-1Pa(或客制化)

4.0*10-1Pa (or customization)

允许导入气体

Gas Allowed

 N2H2Ar(可选任意气体)(选配)

N2, H2, ar (optional gas) (optional)

烧结工艺

Sintering process

 真空、分压烧结、加压烧结

Vacuum, partial pressure sintering, pressure sintering
